GEARBOX LISTING
Below is a list of the current industrial gearboxes we have available. If you can’t find what you’re looking for, please contact the factory for additional options. At Turner Uni-Drive, we are constantly developing new products and adapting old ones to meet our customer’s requirements.
Let us help you choose an industrial gearbox! You can use the following chart for the preliminary selection of a multi-speed gearbox. We offer a wide selection of different models to suit your needs. Because of a wide variety of application requirements, we encourage you to contact us so we can help you choose the right one.
3M
Shaft Diameter:
1.000
Number of Shafts:
4
Max HP:
13
# of Speeds:
9
Max Ratio:
8.00
Max Output Torque:
570
PDF File Autocad File
2M
Shaft Diameter:
1.000
Number of Shafts:
3
Max HP:
13
# of Speeds:
9
Max Ratio:
4.00
Max Output Torque:
570
PDF File Autocad File
E3
Shaft Diameter:
1000
Number of Shafts:
2
Max HP:
17
# of Speeds:
3
Max Ratio:
2.43
Max Output Torque:
725
PDF File Autocad File
5M
Shaft Diameter:
1.125
Number of Shafts:
3
Max HP:
22
# of Speeds:
9
Max Ratio:
4.480
Max Output Torque:
980
PDF File Autocad File
X5MA
Shaft Diameter:
1.375
Number of Shafts:
3
Max HP:
15
# of Speeds:
4
Max Ratio:
4.769
Max Output Torque:
2100
PDF File Autocad File
X5MG
Shaft Diameter:
1.375
Number of Shafts:
2
Max HP:
25
# of Speeds:
2
Max Ratio:
2.000
Max Output Torque:
2.220
PDF File Autocad File
6M
Shaft Diameter:
1.125
Number of Shafts:
4
Max HP:
22
# of Speeds:
9
Max Ratio:
10.648
Max Output Torque:
980
PDF File Autocad File
7UM
Shaft Diameter:
1.375
Number of Shafts:
3
Max HP:
10
# of Speeds:
4
Max Ratio:
6.052
Max Output Torque:
725
PDF File Autocad File
10M
Shaft Diameter:
1.375
Number of Shafts:
3
Max HP:
51
# of Speeds:
9
Max Ratio:
4.456
Max Output Torque:
2.220
PDF File Autocad File
11M
Shaft Diameter:
1.375
Number of Shafts:
4
Max HP:
51
# of Speeds:
9
Max Ratio:
9.409
Max Output Torque:
2.220
PDF File Autocad File
20M
Shaft Diameter:
2.250
Number of Shafts:
3
Max HP:
106
# of Speeds:
6
Max Ratio:
2.616
Max Output Torque:
4.250
PDF File Autocad File
22M
Shaft Diameter:
2.250
Number of Shafts:
2
Max HP:
106
# of Speeds:
2
Max Ratio:
2.000
Max Output Torque:
4.250
PDF File Autocad File
30M
Shaft Diameter:
2.250
Number of Shafts:
3
Max HP:
126
# of Speeds:
9
Max Ratio:
4.000
Max Output Torque:
5.430
PDF File Autocad File
32M
Shaft Diameter:
2.250
Number of Shafts:
2
Max HP:
106
# of Speeds:
2
Max Ratio:
2.000
Max Output Torque:
5.430
PDF File Autocad File
50M
Shaft Diameter:
2.250
Number of Shafts:
3
Max HP:
168
# of Speeds:
6
Max Ratio:
4.000
Max Output Torque:
7.240
PDF File Autocad File
52M
Shaft Diameter:
2.250
Number of Shafts:
2
Max HP:
168
# of Speeds:
2
Max Ratio:
2.000
Max Output Torque:
7.240
PDF File Autocad File
W50M
Shaft Diameter:
2.250
Number of Shafts:
3
Max HP:
252
# of Speeds:
4
Max Ratio:
4.000
Max Output Torque:
10.860
PDF File Autocad File
60M
Shaft Diameter:
2.875
Number of Shafts:
3
Max HP:
300
# of Speeds:
4
Max Ratio:
4.000
Max Output Torque:
18.000
PDF File Autocad File
62M
Shaft Diameter:
2.875
Number of Shafts:
2
Max HP:
300
# of Speeds:
2
Max Ratio:
2.000
Max Output Torque:
18.000
PDF File Autocad File
55MTR
Shaft Diameter:
Number of Shafts:
4
Max HP:
500
# of Speeds:
4
Max Ratio:
18.200
Max Output Torque:
30.000
PDF File Autocad File
55MDR
Shaft Diameter:
Number of Shafts:
3
Max HP:
500
# of Speeds:
4
Max Ratio:
6.000
Max Output Torque:
36.000
PDF File Autocad File
55MSR
Shaft Diameter:
Number of Shafts:
2
Max HP:
500
# of Speeds:
2
Max Ratio:
2.500
Max Output Torque:
40.000
PDF File Autocad File
65MTR
Shaft Diameter:
Number of Shafts:
4
Max HP:
1000
# of Speeds:
4
Max Ratio:
18.200
Max Output Torque:
55.000
PDF File Autocad File
65MDR
Shaft Diameter:
Number of Shafts:
3
Max HP:
1000
# of Speeds:
4
Max Ratio:
6.000
Max Output Torque:
65.000
PDF File Autocad File
65MSR
Shaft Diameter:
Number of Shafts:
2
Max HP:
1000
# of Speeds:
2
Max Ratio:
2.500
Max Output Torque:
85.000
PDF File Autocad File
